Ubbink Lagon Octagonal Wooden Swimming Pool 5.05 x 3.55 x 1.20m
Transform your outdoor space with the premium Ubbink Lagon elongated octagonal wooden swimming pool, crafted from robust Northern Pine treated with Class 4 autoclave preservation for lasting durability against rot, fungi, and insect damage. Engineered with reinforced 45 mm thick interlocking wooden planks and a supportive internal metal cradle, this pool provides exceptional structural rigidity and can be installed above-ground, semi-inground, or fully inground.
This comprehensive swimming pool kit includes everything required for quick setup and effortless maintenance, featuring a powerful sand filtration unit, antibacterial protective felt for the walls and floor, a heavy-duty liner, an interior stainless steel ladder, and a removable exterior wooden ladder.
Key Features
| Brand | Ubbink |
| Model | Lagon |
| Shape | Elongated Octagonal |
| Outer Dimensions | 5.05 x 3.55 m |
| Inner Dimensions | 4.55 x 3.05 m |
| Height | 1.20 m |
| Water Depth | 1.05 m |
| Water Volume | 13.5 m³ |
| Swim Area | 12.5 m² |
| Installation Type | Above-ground, Semi-inground, Inground |
| Wall Thickness | 45 mm |
| Wood Type | Northern Pine |
| Wood Treatment | Class 4 Autoclave (CTB-P+ certified) |
| Coping | Double Northern Fir, 300 mm wide, 27 mm thick |
| Coping Finish | Anodized Aluminum |
| Filtration System | Sand filtration unit |
| Flow Rate | 6 m³/h |
| Pump Power | 0.50 HP |
| Liner Thickness | 0.60 mm (60/100) |
| Ladders Included | Interior 3-step stainless steel, exterior 4-step removable wood |
| Concrete Slab Dimensions | 5.10 x 3.90 m (20 cm thickness) |
| Metal Cradle | 1 (ground channel: 355 x 10 x 18 cm) |
| Standards Compliance | NF P90-316, P90-317, P90-318, P90-319 |
| Structure Warranty | 15 Years |
| Liner Warranty | 10 Years |
| Filtration Warranty | 2 Years |
Highlights
- Durable Northern Pine construction with Class 4 autoclave wood protection
- Versatile installation options: above-ground, semi-inground, or fully inground
- Includes a complete sand filtration unit with pump and filter media
- Features dual ladders: an interior stainless steel ladder and a removable exterior wooden ladder
- Equipped with antibacterial protective ground and wall felt
Videos
Materials & care
The structure of Ubbink pools is made of Northern Pine, originating from the cold regions of Northern Europe. The pool copings are made of Northern White Fir. The harsh climate creates particularly difficult growing conditions for the trees, giving the wood a very fine grain, smaller knots, and mechanical resistance among the best of the softwood species. These woods are impregnable, allowing for the penetration of a fungicide and insecticide treatment to provide effective resistance against attacks from insects, fungi, and termites. Ubbink pool structures are treated to class 4, which corresponds to the use of wood in a systematically humid environment and in contact with the ground. The treatment station is CTB-P+ certified, guaranteeing the procedure and the level of impregnation for all Ubbink wooden parts.
Compatibility
Compatible with above-ground, semi-inground, or fully sunken setups. When sinking the pool, install a dimpled drainage membrane against the outer walls and backfill with gravel as the pool fills with water.
How to use
Install on a perfectly level 20 cm thick concrete base with proper reservations for the metal support cradle. Assemble the interlocking tongue-and-groove wooden planks, fit the protective felt, and install the 60/100 liner before filling with water and connecting the sand filtration unit.
What’s included
Complete filtration unit, Wooden ladder, Stainless steel ladder, Skimmer hatch, Floor felt, Wall felt, Aluminum coping reinforcement, Wall reinforcement
